プロダクト細部
Place of Origin: CHINA
ブランド名: SHANAN
証明: CE, ISO
Model Number: SA-990
支払及び船積みの言葉
Minimum Order Quantity: 1 set
価格: 交渉可能
Packaging Details: Box
Delivery Time: 15work days
Payment Terms: T/T
Supply Ability: 100 set/month
Alarm Mode: |
Sound and Light |
Detection Range: |
0.3-2.5mm |
Humidity: |
≤95%RH |
Material: |
Stainless Steel |
Name: |
Food Metal Detector |
Operation Temperature: |
0-50℃ |
Power Consumption: |
50W |
Power Supply: |
AC220V |
Sensitivity: |
High |
Size: |
Medium |
Type: |
Metal Detector |
Warranty: |
1 Year |
Weight: |
2.5kg |
Working Frequency: |
20-100KHz |
Alarm Mode: |
Sound and Light |
Detection Range: |
0.3-2.5mm |
Humidity: |
≤95%RH |
Material: |
Stainless Steel |
Name: |
Food Metal Detector |
Operation Temperature: |
0-50℃ |
Power Consumption: |
50W |
Power Supply: |
AC220V |
Sensitivity: |
High |
Size: |
Medium |
Type: |
Metal Detector |
Warranty: |
1 Year |
Weight: |
2.5kg |
Working Frequency: |
20-100KHz |
Parameter:
| Item | SA-990 Series | |
| Passing width (MM) | 500~1200(can customize) | |
| Passing height (MM) | 200~1000(can customize) | |
|
standard Detection Sensitivity |
FE(ΦMM) | ≥0.5 |
| NON-FE(ΦMM) | ≥0.8 | |
| SUS304(ΦMM) | ≥1.0 | |
| Protection level | IP67 | |
| Number of memory products | 100 kinds | |
| Display method | LED Screen | |
| Operation method | Touch button input | |
| Alarm mode | Alarm stop, buzzer alarm or reject mechanism optional | |
| Machine material | Carbon steel paint or stainless steel 304,fit for HACCP.GMP.CAS | |
| Machine weight | ≥120KG | |
| power supply | AC200V±10% 50-60HZ(Customize AC110V or AC380V) | |
| Using environment | temperature:-180~50℃,Relative humidity:30~90℃ | |
| Remarks :01 probe detection window, the size of the whole machine can be customized according to customer needs. The higher the height of the detection window, lower the detection sensitivity, wider the detection window, the lower the detection sensitivity. | ||
| 02 Detection sensitivity is the detection sensitivity obtained by placing the test card in the center of the conveyor belt through the detection channel. The actual detection sensitivity will vary depending on the product being tested or the conditions of use. | ||
